Choosing the right intelligent machining tools is particularly important, as they not only improve work efficiency and ensure part quality but also extend tool life—this isn't something you can just do with any random tool. Just as different tasks require different tools, main processes such as turning, milling, and drilling each have their own ways of selecting tools and key points to pay attention to. This article will thoroughly discuss how to accurately select turning tools, milling cutters, and drills based on part material, machining accuracy requirements, and desired surface finish. Additionally, parameters such as the tool's own angles are also crucial; adjusting them properly can enhance cutting performance and control the cutting force and heat during machining. Therefore, understanding the relationship between these core elements and forming a systematic approach to tool selection is essential to efficiently and high-quality complete intelligent machining tasks.

How to choose lathe tools

     Whether the lathe tool is chosen well directly affects the smoothness of the machined part's surface and the speed of work. When selecting a lathe tool, the first thing to consider is the material of the part. For example, when machining high-hardness alloy steel, wear-resistant coated carbide inserts are generally used. These inserts can withstand high temperatures and handle higher cutting temperatures. If machining soft materials like aluminum or copper, sharp uncoated carbide inserts or PCD (Polycrystalline Diamond) inserts should be selected, which can reduce the adhesion of the material to the tool.

     Secondly, cutting parameters are also crucial. When rough turning to quickly remove excess material, you need to select sturdy inserts with chip-breaking grooves, paired with a higher cutting speed and feed rate; when finish turning to ensure a smooth surface and accurate dimensions, you must use sharp-edged, high-precision inserts.

      There are also some special cases, such as when the workpiece surface is uneven, the cutting is intermittent when the tool cuts through, or the tool extends very long. In such situations, it is necessary to choose tool inserts with good toughness and special shapes, for example, using negative rake angles, and ensuring the tool tip radius is sturdy. This way, the tool is less likely to break and can be used for a longer time. In addition, the rake angle, clearance angle, and other angles of the turning tool should also be slightly adjusted according to specific conditions.

Tips for Selecting Milling Cutters

    When selecting a milling cutter, it is necessary to combine the material of the workpiece and the processing requirements to improve efficiency. For example, when machining steel, carbide milling cutters are wear-resistant; when machining aluminum alloy, coated milling cutters can reduce the problem of material sticking to the tool. The cutting speed and feed rate must be properly matched with the type of milling cutter; otherwise, the tool is prone to wear and will not last long.

     Surface smoothness requirements also affect the design of milling cutters, such as the number of cutting edges and the size of the rake angle, which in turn determine the machining accuracy and overall effect. When operators adjust these parameters properly, the milling process becomes more stable, resulting in better quality work.

What are the types of drilling tools?

     Drilling is an indispensable step in intelligent machining. Choosing the right drill bit directly affects the quality and speed of the hole. Common types of drill bits include twist drills, center drills, deep-hole drills (such as gun drills), and indexable drill bits.

Twist drills are versatile and affordable, making them suitable for most standard-sized holes. Center drills are used to position holes before drilling, ensuring accuracy in placement. For deep holes, gun drills are preferred because they have good chip removal and are less likely to deviate. Indexable drill bits have a significant advantage in large-scale production as their cutting inserts can be replaced, resulting in a lower cost per hole.

      When selecting, you need to consider the material of the parts (such as whether it is hard or tough), the size and depth of the holes, as well as the precision (such as whether the hole wall is smooth and straight). For example, when processing difficult-to-drill materials like stainless steel, more wear-resistant cobalt alloy drill bits or coated drill bits are generally used; if the hole requires high precision, step drills or reamers may also be needed for further processing. The angle of the drill bit (such as the point angle, helix angle), blade width, and other factors will also affect chip removal efficiency, cutting force during machining, and the surface quality of the hole.

How should I adjust the geometric parameters?

    In addition to choosing the right tool type, adjusting parameters such as the tool's angles also has a significant impact on the machining effect. Appropriate angles can make the cutting smoother, result in a brighter workpiece surface, and extend the tool's service life.

For example, the size of the rake angle directly affects the cutting force and the smoothness of chip removal. Generally, softer materials use a larger rake angle, while harder materials require a smaller one to ensure the cutting edge is sturdy. As for the clearance angle, it relates to the friction between the tool's flank and the workpiece. If it's too large, the cutting edge is prone to chipping; if it's too small, excessive friction can cause the tool to overheat and wear out quickly.

When it comes to end mills, the helix angle is crucial. A 45-degree helix angle generally balances cutting force and chip evacuation efficiency. For drills, the point angle and web width determine the accuracy of drilling and whether the center can be stabilized; different angles are required for processing different materials.

    When actually working, by combining the material of the parts, cutting speed, and feed rate, adjusting details such as the small chamfer of the tool edge and the width of the land (for example, generally selecting less than 0.1 millimeters for finishing) can significantly reduce burrs and make the machined surface smoother.

     In general, selecting the right cutting tools for machining processes such as turning, milling, and drilling in intelligent machining is a matter that requires systematic consideration. Choosing the right turning tool requires understanding the workpiece material and the desired surface finish; selecting a good milling cutter involves balancing cutting parameters and feed paths; choosing the right drill directly affects the quality and efficiency of the hole. Regardless of which tool is selected, adjusting the geometric parameters to the right level is crucial.

    Understanding these principles and applying these methods can not only extend tool life but also improve work efficiency, ensuring that parts meet the required design precision and quality. In practical operations, by trying more and adjusting more, the level of intelligent machining will gradually improve.
